4 Installation
Setup and assembly of the pads and pedals are described in detail in the enclosed
assembly guide. Finally check that all cables between the pads and the e-drum
module have been properly connected.
Connect the included power adapter to the 9V input of the e-drum module. Then
plug the mains plug into the socket.
Connect your stereo headphones to the [PHONES] output of the drum module.
Connect the inputs of your amplier or active monitors to the [OUTPUT] sockets of
the drum module. If you use a mono amplier, connect its input to the [L/MONO]
output socket of the module.
Connect a CD or MP3 player to the input socket [AUX IN] IN of the drum module.
Connect external MIDI devices to the [MIDI OUT] socket of the drum module.
Connect external MIDI devices or your computer to the USB port of the drum
module.
Connect an additional crash or tom pad to the phone jacks [Crash 2] or [Tom 4].
Setup, connecting pads and pedals
Connecting the power adapter
Connecting headphones
Connecting audio devices
Connecting a CD or MP3 player
Connecting MIDI devices
Connecting USB devices
Connecting additional pads
Installation
MPS-450
9
