3. OPERATION
18
After hook-up to
attachment, check to
be sure lock pins are
fully engaged.
WARNING
REMOVAL OF ATTACHMENTS
1. Lower lift arms and tilt forward on the
attachment so that the attachment is resting on
the ground.
2. If the attachment is hydraulically equipped,
stop the engine, relieve hydraulic pressure in
the attachment lines by partially shifting the
auxiliary lever back and forth and
disconnecting the attachment hydraulic hoses.
3. Rotate the lock pins to the unlocked (handles
pointing outwards) position. See Figs. 3.2 &
3.2A.
4. Start engine, activate the hydraulic safety
interlock switch, tilt the attachment forward
(dump) until the top edge of the attachment
mount frame clears the lip on the attachment.
Back the Mini-Skid Loader away from the
attachment. See Fig. 3.2B.
C4173
Fig. 3.2C
COUPLERS
