45
6. PARTS BREAKDOWN
6.1 MAINFRAME
ITEM PART NO. DESCRIPTION QTY.
1. 38789 Plug, Snap-In 4” 4
2. 48090 Sight Glass 1” NPT 2
3. 5170 Bolt, Hex 1/4” x 1” UNC GR5 PL 4
4. 1193 Bolt, Hex 3/8 x 1/2 PC 9
5. 2338 Bolt, 1/4” x 1/2” 1
6. 964975 Cooler Cover 1
7. 38303 Clamp, Tube Twin 7
8. 964796 Combiner Cover Assembly 1
9. 48902 Step Plate 1
10. 964132 Handle, Welded Assembly 1
11. 51073 Dash Panel 1
12. 965592 Valve Mount Ass’y 1
13. 965216 Valve Mount Cover Welded Ass’y 1
14. 47468 Lamp, Halogen Complete 1
* 47861 Bulb, Halogen (Not shown) 1
15. 47766 R.H. Valve Mount 1
16. 47767 L.H. Valve Mount 1
17. 38870 Battery, 12 V 1
18. 49237 Cooler 1
19. 51379 Upper Front Shield 1
20. 51380 Lower Front Shield 1
21. 36733 Breather, Oil Filler Locking 1
22. 40922 Fuel Cap, Locking 1
23. 42070 Knob 5
24. 964797 Belt Guard Assembly 1
25. 964667 Cooler Fan Shroud 1
26. 47838 In-Tank Oil Filter 1
27. 23459 Bolt, Hex 8 mm x 15 mm x 1.25 mm 3
28. 47470 Nut, 3/8” Hex Flanged 1
29. 2663 Bolt, 1/4” x 3/4” 28
30. 2279 Washer, Lock 1/4” 34
31. 1650 Washer, 1/4” 36
32. 6081 Bolt, 5/16” x 3/4” 4
33. 21029 Washer, Lock 8 mm 4
34. 1870 Washer, Lock 5/16” 16
35. 1651 Washer, 5/16” 12
36. 51384 LH Shield, RH Shield 2
37. 51349 Front Bottom Shield 1
38. 51204 Middle Bottom Shield 1
39. 51205 Back Bottom Shield 1
40. 7465 Nut, Nylok 3/8” UNC 1
41. 1643 Washer, Flat 3/8” 3
42. 920 Trim Lock, Molded, 1/8” 3.27 ft.
