49
6. PARTS BREAKDOWN
6.3 LIFT ARMS
ITEM PART NO. DESCRIPTION QTY.
1. 964509 Lift Arm Welded Assembly 1
(To S/N MD000192)
1. 965365 Lift Arm Welded Assembly 1
(S/N MD000193 Onward)
2. 49334 Cylinder,2 x 14 x 22 2
3. 964510 Parallel Arm Welded Assembly 1
(To S/N MD000192)
3. 965649 Parallel Arm Welded Assembly 1
(S/N MD000193 Onward)
4. 963987 Tilt Support (L.H.) 1
4. 963988 Tilt Support (R.H.) 1
5. 47463 Cylinder Assembly, 2.5” x 6.5” x 3.75” 1
6. 963989 Tilt Support Center Assembly 1
7. 47698 Pin, Q-Tach Pivot 1
8. 47691 Bar, Q-Tach Handle 2
9. 47613 Spring, Compression 2
10. 49298 Pin, Tilt Assembly 1
11. 964511 Q-Tach Welded Assembly 1
12. 49749 Lift Arm Support 1
* 15931 Weather Strip Foam 1.5”
13. 51052 Pin, Lift Cylinder Base 2
14. 51019 Pin, Lift Cylinder Rod End 2
15. 51018 Pin, Lift Arm Pivot 4
16. 51020 Pin, Liftarm to Q-Tach 2
17. 49958 Parallel arm to Q-Tach 2
18. 1672 3/8” x 1 1/2” Bolt 2
19. 7465 3/8” Nylok Nut 2
20. 2580 5/16” x 1 1/4” Bolt 1
21. 16771 5/16” Nylok Nut 1
22. 47832 Angle Bushing 2
23. 1386 Pin, Cotter 3/16” x 2” 2
24. 47693 1/2” x 3/4” Cap Screw 2
25. 23385 1/2” Flat Washer 2
26. 3313 1/4” x 2” Bolt 9
27. 6645 1/4” Nylok Nut 11
28. 49610 Lock Pin 1/4” x 1 3/8” 1
29. 48086 Lanyard 1
30. 3237 1/4” x 2 1/2” Bolt 2
31. 47788 Bushing 10
32. 1677 Bolt, 7/16” x 2 1/2” 2
33. 16771 Nut, 7/16” Nylok 2
