51
6. PARTS BREAKDOWN
6.4 TRACKS
ITEM PART NO. DESCRIPTION QTY.
1. 965277 Axle Weld Assembly R.H. 1
2. 965278 Axle Weld Assembly L.H. 1
3. 964861 Front Hub Welded Assembly 2
4. 51200 Bar, Drive Sprocket Washer 2
5. 964859 Idler Mount Assembly, L.H. 1
6. 964860 Idler Mount Assembly, R.H. 1
7. 51193 Drive Sprocket 2
8. 49339 Wheel, Polyolefin 8
9. 1474 1/2” x 9” Bolt, Hex UNC 4
10. 49953 Conventional Rubber Track, Type G 2
11. 49492 Flange Bolt, 5/8” x 1 1/4” 8
12. 49955 Chain # 60H 62 Pitches, LH 1
12. 49954 Chain # 60H 50 Pitches, RH 1
13. 964548 Axle Welded Assembly 2
14. 964541 Axle Tower Welded Assembly 2
15. 51153 Plate, Front Idler 2
16. 964913 Bolt Cage Welded Assembly 2
17. 964952 Drive Sprocket 2
18. 964863 Plate 2
19. 51340 Bar, Spring Puller 2
20. 51339 Washer 2
21. 49407 Compression Spring 2
22. 49408 Nyloil Wear Pad 4
23. 51367 Wear Guide Support 4
24. 8613 1/2” Nylok Nut 4
25. 23385 1/2” Washer 8
26. 52035 Tensioner Block 2
27. 43559 1/2” Flange Nut 10
28. 3093 Nut, Wheel 20
29. 49501 1 1/2 “Set Screw 2
30. 49342 Wheel Stud, 1 7/8” 10
* - Item not shown.
