53
6. PARTS BREAKDOWN
6.4 TRACKS (Continued)
ITEM PART NO. DESCRIPTION QTY.
31. 49435 Seal 2
32. 16071 Bearing 2
33. 16072 Race 2
34. 26722 Bearing 2
35. 26723 Race 2
36. 47534 Dust Cap 2
37. 1632 Cotter Pin 2
38. 5914 Nut, Cotter 2
39. 8675 Axle Spacer 2
40. 51338 Rear Sprocket 2
41. 20200 1/2” x 1 1/4” Keystock 4
42. 49306 Inner Seal 2
43. 49437 Inner Bearing 2
44. 5968 Race 4
45. 3665 Outer Bearing 2
46. 3667 Outer Seal 2
47. 49581 Bolt, 8 mm x 35 mm 2
49. 7729 15/16” Washer 2
50. 3668 Nut, Castle 7/8” 2
51. 1632 Cotter Pin 4
52. 49471 1/2” x 1 1/4” Bolt, Hex Socket Head 16
53. 20861 1/2” Washer, Lock 16
54. 49341 Wheel Stud, 1 5/8” 10
55. 51332 Plate, Locking Clip 2
56. 51339 Plate, Washer 4
