6. PARTS BREAKDOWN
6.5 HYDRAULIC SCHEMATIC (TO S/N MD000239)
ITEM PART NO. DESCRIPTION QTY.
1. 49015 315 cc Hydraulic Motor 2
2. 49016 Pump, Hydraulic Dual 1
3. 47463 Tilt Cylinder 1
4. 49373 Valve, Hyd SD6/5/AC (JG3) 1
S-1C-SAE-CVN-Q38
5. 47461 Valve, Hyd. SD4/1 (JG3) /11L-SAE 1
6. 48592 Cplg, QU DIS 8 F 8 1/2 NPT 2
Flush face body 1/2
7. 48593 Cplg, QU DIS 8 M 8 1/2 NPT 2
Flush face body 1/2
8. 48594 Cap, Dust for 8 F Flush Face Cplg. 2
9. 48595 Cap, Dust for 8 M Flush Face Cplg. 2
*. 38303 Clamp, Tube Twin 5/8” 10
*. 38472 Plate, Cover Twin 7
10. 49237 Cooler, Oil/Rad Combo 1
11. 49238 Fan, Multiwing 6 Blade 13” Dia. 1
12. 49357 Motor, Hyd. Fan 4.95 cc/Rev SAE “A” 1
13. 49236 Valve, Hyd. Combiner 1
14. 49431 Valve, Relief 1
*. 18767 Plug, Hex Head 6 9/16 ORB M 1
15. 47838 Intank Oil Filter 1
16. 49334 Cylinder,2 x 14 x 22 2
17. 964811 Hose, Hyd 3/4” x 38 9/16” 1
18. 964822 Hose, Hyd 3/8” x 13” 1
19. 964813 Hose, Hyd 1/2” x 18 3/4” 1
*. 964815 Hose, Hyd 3/8” x 27 5/16” 1
20. 965235 Hose, Hyd 5/8” x 28 1/2” 1
21. 965232 Hose, Hyd 1/2” x 15 1/8” 1
22. 964821 Hose, Hyd 3/8” x 15 1/2” 1
23. 964822 Hose, Hyd 3/8” x 13” 1
24. 964823 Hose, Hyd 3/8” x 15 1/8” 1
25. 964824 Hose, Hyd 3/8” x 80 7/8” 2
26. 964826 Hose, Hyd 3/8” x 47 3/16” 2
27. 964825 Hose, Hyd 3/8” x 50” 1
28. 964827 Hose, Hyd 3/8” x 42” 1
29. 964828 Hose, Hyd 3/8” x 40” 1
30. 964830 Hose, Hyd 3/8” x 51” 1
31. 964829 Hose, Hyd 3/8” x 54” 1
32. 964831 Hose, Hyd 3/8” x 20 13/16” 2
33. 964832 Hose, Hyd 3/8” x 23” 2
34. 964833 Hose, Hyd 3/8” x 51” 1
35. 964834 Hose, Hyd 3/8” x 12 3/4” 2
36. 964865 Hose, Hyd 3/8” x 11 5/8” 1
37. 964866 Hose, Hyd 1/2” x 37 1/8” 1
*. 964867 Hose, Hyd 1/4” x 10 1/8” 1
38. 49362 Tube, Hyd 1/2” x 20” LOA T to T 1
39. 49363 Tube, Hyd 1/2” x 12”LOA IN to A 1
* - Item not shown.
