57
6. PARTS BREAKDOWN
6.5 HYDRAULIC SCHEMATIC (Continued)
* - Item not shown.
ITEM PART NO. DESCRIPTION QTY.
40. 49364 Tube, Hyd 1/2” x 29” LOA T to C 1
41. 49360 Tube, Hyd 1/2” x 30” LOA P2 to P2 1
42. 49361 Tube, Hyd 1/2” x 28” LOA P1 to P1 1
43. 965233 Hose, Hyd 1/2” x 16 11/16” 1
44. 965234 Hose, Hyd 3/8” x 40 3/16” 1
45. 49366 Tube, Hyd 1/2” x 25” LOA Front Lift 1
46. 49367 Tube, Hyd 1/2” x 28” LOA Rear Lift 1
47. 49365 Tube, Hyd 1/2” x 20” LOA 1
To Next Page
