Thomas 35DT - Page 63

59
6. PARTS BREAKDOWN
6.5 HYDRAULIC SCHEMATIC (S/N MD000240 Onward)
ITEM PART NO. DESCRIPTION QTY.
1. 49015 315 cc Hydraulic Motor 2
2. 49016 Pump, Hydraulic Dual 1
3. 47463 Tilt Cylinder 1
4. 49373 Valve, Hyd. 1
5. 47461 Valve, Hyd. 1
6. 48592 Female Coupling, 1/2” 2
7. 48593 Male Coupling, 1/2” 2
8. 48594 Dust Cap For Female Flush Faced Coupling 2
9. 48595 Dust Cap For Male Flush Faced Coupling 2
* 38303 Clamp, Tube Twin 5/8” 10
* 38472 Plate, Cover Twin 7
10. 49237 Cooler, Oil/Rad Combo 1
11. 49238 Fan, Multiwing 6 Blade 13” Dia. 1
* 49890 Bushing, Fan 1
12. 49357 Motor, Hyd. Fan 4.95 cc/Rev SAE “A” 1
13. 965333 Combiner Valve Ass’y 1
14. 965538 Hose, Hydraulic 1
15. 47838 Intank Oil Filter 1
16. 49334 Lift Cylinder, 2” x 14” x 22” 2
17. 964811 Hose, Hyd 3/4” x 38 9/16” 1
18. 964819 Hose, Hydraulic 1
19. 965235 Hose, Hydraulic 1
20. 49366 Tube, Hyd. 1/2” x 25” Front Lift 1
21. 965234 Hose, Hyd. 3/8” x 40 3/16” 1
22. 964829 Hose, Hyd. 3/8” x 54” 1
23. 964832 Hose, Hyd. 3/8” x 23” 2
24. 964831 Hose, Hyd. 3/8” x 20 13/16” 2
25. 964824 Hose, Hyd. 3/8” x 80 7/8” 2
26. 49365 Tube, Hyd. 1/2” x 20” 1
27. 964825 Hose, Hyd. 3/8” x 50” 1
28. 964826 Hose, Hyd. 3/8” x 47 3/16” 1
29. 49367 Tube, Hyd. 1/2” x 28” Rear Lift 1
30. 49363 Tube, Hyd. 1/2” x 12” (In to A) 1
31. 49364 Tube, Hyd. 1/2” x 29” (T to C) 1
32. 964826 Hose, Hyd. 3/8” x 47 3/16” 1
33. 964833 Hose, Hyd. 3/8” x 51” 1
34. 49362 Tube, Hyd. 1/2” x 20” (T to T) 1
35. 49360 Tube, Hyd. 1/2” x 30” (P2 to P2) 1
36. 49361 Tube, Hyd. 1/2” x 28” (P1 to P1) 1
37. 964865 Hose, Hyd. 3/8” x 11 5/8” 1
38. 964867 Hose, Hyd. 1/4” x 10 1/8” 1
39. 964828 Hose, Hyd. 3/8” x 40” 1
40. 964827 Hose, Hyd. 3/8” x 42” 1
