THOMSON DTH175EL Service Manual
Servicing Procedures
Power Supply Trouble Service Flow Chart
Power Supply
Block Trouble
NG
Check F901 Condition Replace F901
OK
Check U901 NG
Pin1/Pin2 Replace U901
Condition
OK
Check on D101/D102/
D103/D104/D105
Output Voltage Condition
NG
Check on Q103 Pin1
NG
Replace Q103
Voltage Condition 2~5V
NG
NG
Replace U902 Replace TR901
OK
OK
Check CON1/2
Output Voltage
