Composite Analogy Audio Trouble Service Flow Chart
Composite Analogy Audio Trouble
NG
Check R138 Signal Replace U4
OK
NG
Check U14 Pin2~4 Signal Replace U4
OK
NG
Check U14 Pin28 +5V Check Power Supply
OK
NG
Check U14 Pin21~26 Signal Replace U14
OK
NG
Check U13/U15/U16 Check U13 between
Pin2/6 Signal Pin2/6 and Pin3/5 Parts
OK
NG
Check U13/U15/U16 Check Power Supply
Pin4/8 +/-12V
OK
NG
Check U13/U15/U16 Replace U13/U15/U16
Pin1/7 Signal
OK
Check Q17/Q20 Mute Parts
