THOMSON DTH175EL - AV Output Parts List

THOMSON DTH175EL Service Manual
AV Output parts list
6CH
NO. PART NO. DESCRIPTION QTY LOCATION
Chip Resistor
1 M2R0000030811000 RC-05K000OT 6 L1 L2 L3 L4 L5 L6
Socket
2 M2P000000PH7A000 PH-7A 1 CN2
3 M2P11AV684120004 AV6-8.4-12-04 1 CN1
PCB
4 M2B100HY5996CH11 HY599-6CH Ver1.1 1 PCB (one side)
SCART
NO. PART NO.
DESCRIPTION
QTY
LOCATION
Capacitor
1 M2C0101F30080500 CC-0805CG101JN500T 8 C1~C8
Jumper Wire
2 **************** J-4.5~10mm 2 A1 A2
Socket
3 M2P000000PH9A000 PH-9A 1 CN_2
4 M2P99000CS103000 CS-103 1 SCART
Screen Cushion
5 M2A00SCART000000 SCART 1
Chart NO.：0SCART-24-01
PCB
6 M2B00000HY811001 HY811-001 VER: B 1 PCB
