THOMSON DTH175EL - Front Panel Parts List

THOMSON DTH175EL Service Manual
Front panel parts list
NO. PART NO. DESCRIPTION QTY LOCATION
Carbon Resistor
1 M2R1147130633110 RT13-1/6W-470R±5% 1 R2
2 M2R1110330633110 RT13-1/6W-10K±5% 6 R1 R4 R5 R6 R9 R10
3 M2R1151330633110 RT13-1/6W-51K±5% 1 R3
Porcelain Capacitor
4 M2C1101F44000022 CC1-50V-101-K 3 C5 C6 C7
5 M2C1104F84000022 CT1-50V-104-Z 2 C3 C4
ELECT Capacitor
6
M2C2107B57051122 CD11-16V-100UF-M
（
5×11
）
2C1 C2
Diode
7 M2D1IN4148110000 1N4148-
（
D0-35
）
3D2 D3 D4
LED Light
8 M2D100374N220000 LT0374N-43-M1 1 D1
IC
9 M2I00PT696100000 PT6961-SOP32 1 U2
IR
10 M2IAT138BST15M20 AT138BST-15M2 1 U3
Jiggle Switch
11 M2S0KFCA06D05001 KFC-A06-2WB
（
230g) 1 POWER
12 M2S00KAO06060501 Jiggle Switch 6*6*3.1 5 S2 S3 S5 S6 S7
LE
D
13 M2G11LCM07013G00 LC-MO7013G 1 U1
Potentiometer
14 M2V11121NL200103 WH121N-2-A10K-F15 2 X1,X2
Jump wire
15 **************** J-5MM 3 J7,J8,J12
16 **************** J-7.5MM 8 J1,J2,J3,J9,J10,J11,J13,J15
17 **************** J-10MM 3 J4,J5,J16
18 **************** J-15MM 1 J6
Sponge mat
19 M4P4400500503522 W5*L5*H3.5 2 LED
PCB
20 M2B0HY122AP0502A HY122A-818-00S VER1.1 1 one side
P/N:0502A
21 M2B0KEYBOARD0000
KEYBOARD
1 one side
22 M2B0VOLBOARD0000 VOL BOARD 1 one side
