Composite Video Trouble Service Flow Chart
Composite Video Trouble
NG
Check “SETUP” Item See “User Manual”
OK
NG
Check Y1 Output Signal Replace Y1 Parts
OK
NG
Check C55/C56 Signal
Replace C55/C56
OK
NG
Check D12/D14 Signal Replace D12/D14
OK
NG
Check Q12 Pin Signal Replace Q12 around parts
OK
OK
Check J5 Pin9 Signal Check External Set
NG
Replace J5 connection
