Aspect ratio: 4:3 Letterbox, 4:3 Pan & Scan, 16:9, Auto
Audio Decoder
Audio support: AAC/Dolby Digital Plus*/AC3+/PCM
MPEG MusiCam Layer II
Sampling rate: 32, 44.1, 48 KHz
Audio mode: Stereo, Mono
*Dolby and the double-D symbol are registered trademarks of Dolby Laboratories
Tuner
Front End: DVB-T, UHF & VHF Tuner
Input frequency range: 174 – 230 MHz (VHF) and 470 - 862 MHz (UHF)
Loop through frequency range: 47 - 862 MHz
Input signal level: -20 ~ -84 dBm
Memory and System
Flash memory: 4 MB
SDRAM: 64 MB
Multimedia
Video playback: MPEG-1 and MPEG-2 encoded (mpg), VOB, AVI, MKV, TS, M2T,
M2TS, MPEG-4 and MOV*
Audio playback: MP3 and OGG*
Picture view: BMP and JPEG*
*THOMSON cannot guarantee the playback of all files although extensions are listed, as it depends on codec used,
data bit rate and resolution (all MPEG codec formats are supported).
Connectors
ANT IN - IEC Female
ANT OUT - IEC Male
HDMI
TV SCART (RGB, CVBS, Audio L&R)
S / PDIF (coax.)
3.5 mm stereo audio jack (audio left/right)
USB 2.0 port: 5 V/800 mA (max.) supported
General Data
Supply voltage: 220 - 240 V AC (SMPS), 50/60 Hz
Power consumption: 4.17 W (typ.), 12.00 W (max)
Power consumption in standby: max. 0.4 W
Operating temperature: 0 ~ +40° C
Storage temperature: -10 ~ +50° C
Operating humidity range: 10~85%, RH, Non-condensing
Size (WxDxH) in mm: 148 x 130 x 37
Net-weight: 0.26kg
