12. CABLE TERMINAL INFORMATION
TERMINAL RATING
CONNECTION TIGHTNESS
(In-lbs)
BASIC MODEL
QTY
PER PHASE
RANGE
TERMINAL
MOUNTING
SCREW
CABLE CLAMP
TS88xA-0100
1 #14-1/0
120 50
TS88xA-0150
1 #2–4/0
120 120
TS88xA-0200 1 #6–350MCM 150 275
TS88xA-0250 1 #6–350MCM 150 275
TS88xA-0400
1
2 2/0–500MCM 72 275
TS88xA-0600
1
2 2/0–500MCM 72 275
TS88xA-0800
1
3 2/0–500MCM 110 375
TS88xA-1000/1200
1
4 4/0–500MCM 375 375
TS88xA-0800/4000
2
As Req’d #2–600MCM -- 450
1. With molded case power switching units
2. With insulated case power switching units
3. For other model types not shown, contact Thomson Technology for further information.
