Use the supplied RCA phono cable to connect the
turntable output to the phono input of your amplifier.
Check that all plugs are connected with the correct po-
larity. ➔ Fig. 7
In accordance with RIAA standards, vinyl records are
cut with pre-emphasis. The operation of a turntable
therefore requires the use of a phono stage for equal-
isation. If your amplier does not have a phono input,
you will need to connect a dedicated phono stage
(such as the Thorens MM series phono stages) be-
tween the turntable and the amplier. Please contact
your Thorens dealer or distributor for further advice.
The earth wire is used to establish an electrical con-
nection to earth. Connect the wire to the earth screws
on the turntable (➔ Fig. 7, indicated by an arrow) and the
amplifier. If your amplifier does not have an earth screw,
you can attach the wire to the side of an unused input
socket.
If you can hear a hum in the speakers that increases
as you increase the overall volume, then the earth
connection may be faulty. Make sure that the earth
wire is rmly connected. If the problem persists, try
connecting the wire to a different spot.
29
Connections
Fig. 7
