35
Operation
The on/off switch is located at the front left-hand cor-
ner of the turntable plinth. This switch is also the speed
selector. There are two speeds: 33 ⅓ rpm (for LPs) and
45 rpm (for singles). The middle position is the “off” po-
sition. ➔ Fig. 15
To play a record, first start the turntable by selecting
the appropriate speed. Then engage the tonearm lift
(➔ Fig. 16) by lifting its lever, position the pick-up car-
tridge over the run-in groove or the desired track and
lower the tonearm lift.
The turntable does not feature an automatic shut-
off mechanism. Therefore, as soon as the stylus has
reached the run-out groove, engage the tonearm lift and
switch the turntable off.
Fig. 16
Fig. 15
