EXULUS-HD1 & EXULUS-4K1 Spatial Light Modulators Chapter 3: Description
Rev I, October 18, 2022 Page 7
Figure 11 Rear side of EXULUS-4K1/M
Callout
Description
1
Item #
2
Serial Number
3
USB 2.0 Connector
4
HDMI-Compatible Connector
5
Trigger Output Connector (SMA), 3.3 V TTL
6
Power Switch
7
DC Input
3
4
5
7
2
1
6
