Chapter 4 Software & Electrical Installation
4.4 Verifying Software Operation
4.4.1 Initial Setup
1) Run the Kinesis softwareand check that the Graphical User Interface (GUI) panel
appears and is active.
Fig. 4.2 Gui panel showing jog and ident buttons
2) Click the ‘Ident’ button. The POWER LED on the control keypad flashes. This is
useful in multi-channel systems for identifying which driver unit is associated with
which GUI.
3) Click the jog buttons on the GUI panel and check that the associated stage moves.
The position display for the associated GUI should increment and decrement
accordingly.
Note
If the Kinesis software does not recognise the unit, switch OFF the power but leave the
kinesis software running and the USB connected. Wait around 30 seconds then switch
the power ON. Kinesis should now load the unit.
