THORLABS LTS Series - Chaper 7 Software Reference; Introduction; GUI Panel

Page 21 16275-D03
LTS Series Long Travel Stages
Chapter 7 Software Reference
7.1 Introduction
This chapter gives an explanation of the parameters and settings accessed from the
Kinesis software running on a PC.
7.2 GUI Panel
The following screen shot shows the graphical user interface (GUI) displayed when
accessing the LTS controller using the Kinesis software.
Fig. 7.1 LTS Stage Software GUI
Position window - shows the position (in
millimetres or degrees) of the motor. The motor
must be 'Homed' before the display will show a
meaningful value, (i.e. the displayed position is
relative to a physical datum, the limit switch).
Move - Opens the settings window, so that position data and velocity
parameters can be entered - see Section 6.4. Moves are performed using the current
velocity parameters which can be changed in the same panel. The present settings
are displayed below the window.
Velocity Parameters - the present setting for the move velocity
parameters and the jog step size. The travel range of the
associated stage/actuator is also displayed.
Note
The serial number of the LTS Stage associated with the GUI panel is displayed in
the top right hand corner. This information should always be provided when
requesting customer support.
