Rev K Jan 2020
Page 30
Chapter 7 Software Reference
7.3.4 Stage/Axis Tab
Fig. 7.7 LTS Series Stage - Stage/Axis Settings
Note
This tab contains a number of parameters which are related to the physical
characteristics of the particular stage being driven. They need to be set accordingly
such that a particular stage is driven properly by the system.
For LTS stages, the Kinesis software will automatically apply suitable defaults for the
parameters on this tab during boot up of the software and these parameters should
not normally be altered subsequently as it may adversely affect the performance of
the stage. Descriptions are provided for information only.
For custom stage types not available using the Kinesis software, the stage details
must be entered manually - see the software overview for more details.
