Rev K Jan 2020
Page 24
Chapter 7 Software Reference
7.3 Settings Panel
When the 'Settings' button on the GUI panel is clicked, the 'Settings' window is
displayed. This panel allows motor operation parameters such as move/jog velocities,
and stage/axis information to be modified. Note that all of these parameters have
programmable equivalents (refer to the Kinesis Server helpfile for further details.
7.3.1 Persisting Settings to Hardware
Many of the parameters that can be set for the LTS Stage can be stored (persisted)
within the unit itself, such that when the unit is next powered up these settings are
applied automatically. This is particularly important when the driver is being used
manually in the absence of a PC and USB link. The Velocity Profile and Jogging
parameters described previously are good examples of settings that can be altered
and then persisted in the driver for use in absence of a PC. To save the settings to
hardware, check the ‘Persist Settings to the Device’ checkbox before clicking the ‘OK
button.
Caution
The ‘Persist Settings’ functionality is provided to simplify use of the unit in the
absence of a PC. When the unit is connected to a PC and is operated via
KinesisUser, the default KinesisServer settings will be loaded at boot up, even
if the ‘Persist Settings’ option has been checked.
