LTS Series Long Travel Stages
3.3 Mounting to a Work Surface
3.3.1 General
When mounting the LTS stage close to other equipment, ensure that the travel of the
moving platform is not obstructed. If equipment mounted on the moving platform is
driven against a solid object, damage to the internal mechanism could occur. The
range of travel for each model is as follows: LTS150 - 150mm, LTS300 - 300mm.
Caution
When siting the unit, it should be positioned so as not to impede the operation
of the control panel buttons.
Ensure that proper airflow is maintained to the unit.
Caution
Remove power from the unit before bolting or unbolting from the work surface.
