Page 31 16275-D02
LTS Series Long Travel Stages
6) Enter a 6 digit serial number.
7) Click the 'Add' button.
8) Repeat items (1) to (7) as required. (A unit can be removed from the configuration
by selecting it in the 'Loaded Configuration Details' window and clicking the
'Remove' button or by right clicking it and selecting the 'Remove' option from the
pop up window).
9) Enter a name into the 'Configuration Names' field.
10) Click 'Save'.
11) Click 'Set As Current' to use the configuration.
Note
Each physical APT hardware unit is factory programmed with a unique 8 digit serial
number. In order to simulate a set of ‘real’ hardware the Config utility allows an 8 digit
serial number to be associated with each simulated unit. It is good practice when
creating simulated configurations for software development purposes to use the
same serial numbers as any real hardware units that will be used. Although serial
numbers are 8 digits (as displayed in the ‘Load Configuration Details’ window, the
first two digits are added automatically and identify the type of control unit.
The prefixed digits relating to the LTS series stages are:
45xxxxxx - LTS Series Motorized Stages
