THORLABS MDT693B User Manual

Open-Loop Piezo Controllers Chapter 7: Remote Communications
Page 20 Rev C, July 7, 2015
The following list shows all available commands and queries, and summarizes
their functions for the MDT694B:
Command
a
Syntax
b
Description
Get Commands ? List the available commands.
Product Information id?
Returns the product header and firmware
version
Restore Default
Settings
restore Restores default factory settings
Get Echo Command
Value
echo? Returns echo status
Set Echo Command echo=n
Sets Echo mode. When the echo mode is
on the command parameters will be
returned, or echoed back, to the
communication program.
(Values: 1 = enable; 0 = disable)
Limit Switch Setting vlimit?
Returns output voltage limit setting.
(75V = 0; 100V = 1; 150V = 2)
Get Display Intensity intensity? Returns the display intensity
Set Display Intensity intensity=n Set the Display Intensity (0-15).
Read X-Axis Voltage xvoltage? Returns the X axis output voltage.
Set X-Axis Voltage xvoltage=n Set the output voltage for the X axis.
Read Min. X-Axis
Voltage
Xmin?
Returns the minimum output voltage
limit for X axis.
Set Min. X-Axis Voltage xmin=n
Sets the minimum output voltage
limit for X axis.
Read System Min.
Voltage
sysmin?
Returns the minimum output voltage
for the system.
Set System Min. Voltage sysmin=n
Sets the minimum output voltage
for the system.
Read Max. X-Axis
Voltage
Xmax?
Returns the maximum output voltage limit
for X axis.
Set Max. X-Axis Voltage xmax=n
Sets the maximum output
voltage limit for X axis.
Read System Max.
Voltage
sysmax?
Returns the maximum output
voltage for the system.
Set System Max.
Voltage
sysmax=n
Sets the maximum output voltage
for the system.
Get voltage adjustment
resolution
dacstep? Reads the current step resolution
Set voltage adjustment
resolution
dacstep=n
Sets the step resolution when
using up/down arrow keys
(n = 1 to 1000)
Increment Voltage Up arrow
Increments the current channel voltage
by resolution set in dacsteps
Decrement Voltage Down arrow
Decrements the current channel voltage
by resolution set in dacsteps
Get Friendly Name friendly? Returns the friendly name.
Set Friendly Name friendly=string Sets the friendly name.
