THORLABS Redstone OSA305 Manual

Optical Spectrum Analyzers Chapter 11: Technical data
Page 37 STN053070-D02
11.5. Trigger Specifications (Redstone OSA305 only)
11.6. Interlock Specifications (Redstone OSA305 only)
11.7. Internal Sources Specifications
Contact Specifications
Trigg, AUX In
Schmitt Trigger Input with 10 kOhm Pull-Up Resistor to +5 V
Positive-Going Threshold Voltage, Min: 1.3 V Max: 2.5 V
Negative-Going Threshold Voltage, Min: 0.6 V Max: 1.8 V
Hysteresis Voltage, Min: 0.4 V Max: 1.5 V
Maximum Input Volta
g
e: +5.5 V
Acquiring Data, AUX Out
LOW-Level Output Voltage Max 0.1 V (I ≤ 100 µA)
HIGH-Level Output Volta
g
e Min 4.7 V
(
I ≤ 100 µA
)
Interlock Specifications
Interlock Switch Requirements
Must be Normally Open Dry Contacts,
Appl
y
No External Volta
g
es to the Interlock Input
Type of Mating Connector 2.5 mm Mono Phono Jack
Open Circuit Voltage 5 VDC
Short Circuit Current (Typical) 0.5 mA
OSA20xC
Redstone OSA305
Source Type
Frequency-Stabilized
Lase
r
Alignment Laser
Frequency-Locked
Laser
Usage
Alignment and
Reference
Alignment Reference
Wavelength 633 nm 636 nm 1.53 µm
Maximum Output Power < 80 µW < 100 µW < 10 mW
Beam Divergence ~ 0.2 rad ~ 0.2 rad ~ 0.2 rad
