2.4. Product specifications
Table 2-1.EB5 Specifications
Item Specifications
OS
Ubuntu18.04
Platform
(Snapdragon™ QRB5165, AI
Performance: 15 TOPS)
CPU: Qualcomm® Kryo
TM
585 CPU, CPU Clock Speed: up to 2.84GHz
GPU: Qualcomm® Adreno™ 650 GP
DSP: Qualcomm® Hexagon™ 698 Processor
VPU: Adreno™ 665 VPU,
H264 & H265 codec support; video decoding: 8k@60fps; video encode: 8k@30fps
ISP: Qualcomm Spectra
TM
480 image processing
System Memory RAM: 8GB, LPDDR5(POP)
Storage
Flash: 128G UFS3.0 on board
Expansion: SD Card, SSD
Display
2x HDMI out, 1080p@60fps
USB 4x USB 3.0 Type A, 1x USB3.1 Type C(OTG)
Micro SD 1x Micro SD Slot
SIM 1x Nano SIM card slot
Ethernet 2x Gigabit Ethernet(10/100M/1000M)
COM Port 2x RS232, 2x RS485
CAN 2x CAN bus
DI/DO 8 DI/DO(4 DI, 4 DO)
Wireless Connectivity
WIFI: 802.11a/b/g/n/ac/ax, 2x2 MIMO
5G: M.2 5G module(optional), multimode support:2G/3G/4G/5G NR sub-6
Antenna: 6x Antenna connector (2x for WIFI,4x for 5G)
Audio 1x MIC, 1x Earphone
Debug Port 1x Micro USB (for debug)
Input & Indicators
Buttons: Power key, Reset key
LEDs: Power status, WIFI status,5G status
Others CR2032 RTC Battery
DC input
19V DC (can support 12v~24v DC)
Mechanical
Waterproof：IP40 Level Design
Dimension: 200mm*235.5mm*44mm
Net weight: 2200g(box body only), 2638g(body and adaptor included)
Mount: Desktop, Wall Mount
Environment
Operation Temperature: -10-50 centigrade
note1
Storage Temperature: -20-70 centigrade
Storage Humidity: 10%~90%, non-condensing
Anti-Vibration: 0.5Grms @ 5 ~ 500 Hz, random
Certification CE, FCC
note2
, JATE/TELEC, RoHS/Reach
Note：
Note1：Test under typical application.
