30
man_vd6s2-de-130515
1: LED display
2: Pressure dimension
3: LED SP1: setpoint 1 / upper switchpoint
4: LED: setpoint (for 3-state-control)
5: LED SP2: setpoint 2 / lower switchpoint
6: LED: control on
7: Menu-key
8: Set-key
9: Up-key for value adjustment
10: Down-key for value adjustment
11: Recorder output
12: Connector for transducer
13: USB interface
14: Relay 1 for switchpoint 1
15: Relay 2 for switchpoint 2
16: Mains connector
