Thyracont VD6 - 7 Technical Data

50
man_vd6s2-de-130515
7 Technical Data
Display LED 13mm; max. 4 ½ digits
display unit mbar (Torr on request)
Display Refresh Rate 2 Hz (0,5s)
Scanning Rate 20 Hz (50 ms)
Voltage Supply VD6S2230: 230 VAC, 50/60 Hz
VD6S2115: 115 VAC, 50/60 Hz
Power Consumption max. 3,5 W
Fuse VD6S2230: 100 mA/T
VD6S2115: 200 mA/T
Operating Temperature 5...50
o
C
Storage Temperature -20...+60
o
C
Signal Input 4-20 mA, SubD female 9pin
e.g. f. transmitter VSC43MA4, VCC200MA4 or VSP63MA4
Switching Outputs 2 x relay contact, potential free, switch-over,
Phoenix strip terminal 3pin each:
2 A / 250 VAC, 1 A / 30 VDC (normal closed)
5 A / 250 VAC, 5 A / 30 VDC (normal open)
Recorder Output 0-1 V or 0-10 V
Serial Interface Mini USB Type B, Virtual Com Port Protocol
Dimensions 96 x 48 x 142 mm; panel: 90 x 42 mm
Protection Class IP 20
Weight 410 g
