Thyracont VD6 - Page 46

46
man_vd6s2-de-130515
set
set
VD6 with transducer type 7 / VCC200MA4:
0 – 10 V, linear;
0.05 V / mbar
VD6 with transducer type 9 / VSP63MA4:
0 – 10 V, logarithmic; (1V per Dekade)
1.5 V corresponds to 1x10
-4
mbar;
8.5 V corresponds to 1000 mbar
To configure the recorder output switch the VD6 into configuration mode as
described in chapter 5, so that the display shows "typ ..".
Press the menu key (several times) until the display shows "Pout".
Press the set key, the current setting for the recorder output is shown.
You can now toggle between "1" and "10" by means of the "Up" and
"Down" keys.
Confirm with "Set" key.
The display then shows the next configuration point. In order to return to meas-
urement mode quit all further configuration points by pressing the menu key.
V
out
(V) =
0.
05 p(mbar)
p (mbar) = V
out
(V) / 0.05
V
out
(V) = log (p(mbar)) + 5.5
p (mbar) = 10
(Vout(V) - 5.5)
