ThyssenKrupp orion Installation Manual

01/09/2014 Orion Optional Installation Manual
8
4. Alarm system HELPY
Press the button on the telephone keypad corresponding to
the symbol shown.
It indicates any phone digit: this symbol is used in the
programming description generally to indicate entries by the
operator.
Raise the inside micro telephone. You must have enabled
programming.
Raise the inside micro telephone.
Hang up the inside micro telephone.
Brackets indicate portions of code that are optional and
therefore may be omitted.
Fi
g
ure 16 - Combiner terminal board
