SETTING AND COMMISSIONING
57
NA016 - Manual - 05 - 2022
CB Diagnostic Off
74 TCS Off
IE>def 0.030 lEn
tE>RES 50 ms
IE>>def 0.050 lEn
tE>def 0.04 s
tE>def 1.00 s
tE>>RES 50 ms
50N / 51N
Circuit breaker
Clear
Store
Set
Test
Reset
Records stored 0
Last record 0
Records state Acquire
Info
Oscillography
protocol RS485 Modbus
Address 1
Baudrate RS485 9600
Enable TX delay 2 ms
Start TX delay 1 ms
Test I> led >
Test I>> led >
Test I>>> led >
Test IE> led >
Test IE>> led >
Test I> full >
Test I>> full >
Test I>>> full >
Test IE> full >
Test IE>> full >
Reset counters >
Reset alarm >
Option
Set default PAR
Set default REE
Test off >
Set month 7
Set day 24
Set hour 9 h
Set minute 22 m
Set second 0 s
Set year 2009
Communication
Time
I curve IEC/BS B
I>inv 1.00 ln
I>>def 7.00 ln
t>inv 1.00 s
t>>def 0.03 s
t>>RES 0 ms
I>>>def 7.00 ln
t>>>def 0.03 s
t>>>RES 0 ms
50 / 51
