TECHNICAL DATA

• 80...1000 MHz AM 80% 10 V/m

• 900 MHz Pulse modulated 10 V/m

Reference standards EN 60255-22-4 IEC 60255-22-4

EN 61000-4-4 IEC 61000-4-4

Fast transient burst (5/50 ns)

• Auxiliary power supply 2 kV

• Input circuits 4 kV

Reference standards EN 60255-22-5 IEC 60255-22-5

EN 61000-4-5 IEC 61000-4-5

High energy pulse

• U

aux

(line-to-ground 10 ohm, 9 mF) 2 kV

• U

aux

(line-to-line 0 ohm, 18 mF) 1 kV

• I/O ports (line-to-ground 40 ohm, 0.5 mF) 2 kV

• I/O ports (line-to-line 40 ohm, 0.5 mF) 1 kV

Reference standards EN 60255-22-6 IEC 60255-22-6

EN 61000-4-6 IEC 61000-4-6

Conducted radio-frequency ﬁelds

• 0.15...80 MHz AM 80% 1kHz 10 V

Reference standards EN 60255-22-7 IEC 60255-22-7

EN 61000-4-16 IEC 61000-4-16

Power frequency

• Dc voltage 30 V

• 50 Hz continuously 30 V

• 50 Hz 1 s 300 V

• 0.015...150 kHz 30 V

Reference standards EN 61000-4-8 IEC 61000-4-8

Magnetic ﬁeld 50 Hz

• 50 Hz continuously 100 A/m

• 50 Hz 1 s 1 kA/m

Reference standards EN 61000-4-10 IEC 61000-4-10

Damped oscillatory magnetic ﬁeld

• Damped oscillatory wave 0.1 MHz 30 A/m

• Damped oscillatory wave 1 MHz 30 A/m

— Emission

Reference standards EN 60255-25 IEC 60255-25

EN 61000-6-4 IEC 61000-6-4

EN 55011 CISPR 11

Electromagnetic emission tests

• Conducted emission auxiliary power supply 0.15...0.5 MHz 79 dB mV

• Conducted emission auxiliary power supply 0.5...30 MHz 73 dB mV

• Radiated emission 30...230 MHz 40 dB mV/m

• Radiated emission 230...1000 MHz 47 dB mV/m

— Mechanical tests

Reference standards EN 60255-21-1 EN 60255-21-2 RMEC01

Vibration, shock, bump and seismic tests on measuring relays and protection equipment

• EN 60255-21-1 Vibration tests (sinusoidal) Class 1

• EN 60255-21-2 Shock and bump test Class 1

— Climatic tests

Reference standards IEC 60068-x ENEL R CLI 01 CEI 50

Ambient temperature -25...+70 °C

Storage temperature -40...+85 °C

Relative humidity 10...95 %

Atmospheric pressure 70...110 kPa

— Safety

Reference standards IEC 60255-27

Pollution degree 3

Reference voltage 250 V

Overvoltage category III

— Certifications

Product standards EN 50263

CE Conformity

• EMC Directive 2014/30/EC

• Low Voltage Directive 2014/35/EC

Type tests IEC 60255-1

XMR-D EQUIPMENT MANUAL

Ed. 2.9 - 02/2021
