Tilgin HG2300 series Quick Guide
Pos Interface Outlet &
cable
color codes
Function
1
Multipurpose
ECO button
Green
-Connects to Wireless Local Area
Network (WLAN) ON or OFF
-Sets up Wireless Protected
Setup (WPS)
Note: The function of the ECO
mode button can be configured
in the Web GUI or setup by the
operator. The default
configuration switches WLAN
on/off.
2
3
USB Host Ports Connects USB Device
4
LAN ports:
A,B,C,D
Yellow Connects Ethernet cables (RJ-45)
to the home computers and other
devices
5
WAN Gray Connects to WAN(Internet)
6
Power Input Black Connects the power adapter
7
ON / OFF Button for turning the home
gateway on or off
8
Reset Button for factory reset
9
Phone 1 Green Connects analogue phones or fax
equipment
10
Phone 2 White
