Timberk T-AC07-S27-Y User Manual

IM2019
7
Max. refrigerant
pipe length
m
10
10
12
15
18
Maximum
difference in
level
m
7
7
7
10
10
Operating
temperature
range: cooling
°C
16~48
16~48
16~48
16~48
16~48
Operating
temperature
range: heating
°C
-10~32
-10~32
-10~32
-10~32
-10~32
Filling of
refrigerant
g
400
540
610
1000
1450
Distance
between
brackets
(outdoor unit)
mm
431*278
431*278
500*260
546*300
540*335
Service area of
the device
m
2
8-13
11-17
14-23
22-35
29-46
Annual energy
consumption
(cooling mode)
kW*h/year
343
420
593
923
1211
Operating mode
(cooling/cooling
+ heating)
-
cooling +
heating
cooling +
heating
cooling +
heating
cooling +
heating
cooling +
heating
Cooling type
(air/water)
-
air
air
air
air
air
Compressor
-
Toshiba
Toshiba
Toshiba
Hitachi
Hitachi
Maximum
operating
pressure
of refrigerant
circuit
(discharge/suction)
MPa
4.15/1.15
4.15/1.15
4.15/1.15
4.15/1.15
4.15/1.15
Net weight
(indoor unit)
kg
8
8.5
9
11
12
Net weight
(outdoor unit)
kg
20
21
25
37
39
Gross weight
(indoor unit)
kg
9.5
10
10.5
13
14
Gross weight
(outdoor unit)
kg
22
23
27.5
40
43
Net dimensions
(indoor unit)
mm
690×283×199
690×283×199
750×285×200
900×310×225
900×310×225
Net dimensions
(outdoor unit)
mm
665×420×280
665×420×280
660×500×240
800×545×315
825×655×310
Packing
dimensions
(indoor unit)
mm
760×345×280
760×345×280
820×345×280
970×380×305
970×380×305
Packing
dimensions
(outdoor unit)
mm
760×470×345
760×470×345
780×550×345
920×605×395
945×435×725
8. INSTALLATION OF THE DEVICE
Important Notices:
 Before installing, please contact with local authorized maintenance center, if unit is not
installed by the authorized maintenance center, the malfunction may not be solved, due to
discommodious contact. To move and install air conditioner to another place, also please
contact our local special service center.
 The air conditioner must be installed by professionals according to the national wiring rules
and this manual.
