Timberwolf TW 230DHB - Page 6

TW 230DHB
4
/ 55
PARTS LOCATOR
C190-0101 25.07.2017 Rev: 1.0
JOCKEY WHEEL ASSEMBLY
FUEL TANK
ENGINE BLOCK
ROTOR
FAN
S
ECTION (x4)
ROTOR
PULLEY
FUEL PUMP
FUEL FILTER
CUTTER BLADE
(x2)
O
IL FILTER
STARTER MOTOR
RADIATOR
HYDRAULIC PUMP
ELECTRICAL PANEL
HYDRAULIC TANK
CONTROL PANEL
BELT TENSION ADJUSTER
IN‐LINE FUEL FILTER
DIRECTIONAL
C
ONTROL VALVE
EXHAUST
TOOL BOX CONTENTS:
Copper Ease •
Rotor locking tool •
Combination Spanner (17mm/19mm)•
Support Bracket x 2•
Lock Unit Keys x 2•
Ignition Keys x 2•
Access Cover Keys x 2•
Keyring•
DRIVE
PULLEY
