Fluidity 2014-2015
- 26 -
Preparing the Power Unit V2 (refer to CAMPAGNOLO documentation)
- Attach the Power Unit V2 clamp to the frame with the threaded nuts (fig.32)
- Run the Power Unit V2 wires through the frame then install the plug (fig.33)
Connector
wires
Grommet
Figure 33
Figure 32
