Fluidity 2014-2015
- 14 -
2) Assembling an electronic gear-shifting system
Important: wiring a frame is a delicate operation which should be entrusted to a qualified specialist:
retailer approved by Time, distributor, etc.
For any specific questions about electrical elements and not related to the frame, refer to the groupset
manufacturer's technical instructions and manuals.
TIME Fluidity framesets come with a preassembly for mechanical groupsets
To fit an electronic groupset to your bicycle, you must first remove any parts dedicated to mechanical
derailleurs
A specific set (P/N: 55007940) must also be used to guarantee full compatibility with other available
groupsets (SHIMANO Di2 or CAMPAGNOLO EPS)
Disassembling mechanical derailleur parts
Remove the adjustable cable housing stops from the down tube by loosening the POSIDRIV screws
Then install the plugs (fig.13)
