Fluidity 2014-2015
- 36 -
Replacing the rear derailleur hanger
- Loosen the 2 M3 screw using a crosspoint
screwdriver (P/N: 60001487)
- Remove the damaged derailleur hanger
- Slightly lubricate the supporting face on the
frame
- Install the new derailleur hanger
(P/N: 55003337)
- Tighten the 2 M3 Phillips head screws
Note: After a few dozen kilometres, check that the M3 Phillips head screws are tight
3) Cleaning
- Use eco-friendly neutral products
- Do not use high pressure cleaners
- Wipe down the module using a soft cloth
Important: Do not use abrasive products such as polish. Eliminate grease stains and marks using White
Spirit or similar solvents
