Fluidity 2014-2015
- 6 -
2) Fit the assembly to the Fluidity module/frame
The seat collar must be installed on the frame, screws loose
Drive the seat post straight into the frame without turning (fig.3)
To ensure that the seat post will stay in place, we would advise not to lubricate it. However, if it does
need to be lubricated, apply on the interior surface of the frame, without lubricating the clamp's
clamping surface (point of contact between clamp and stem) or the seat!
3) Clamping the seat collar
Once the seat height is adjusted, torque the seat collar to 5Nm, tightening each screw gradually and
alternately (fig. 4)
torque
insertion
