2
3
• Wi-Fi Specification: 2.4 GHz b/g/n
• Frequency Range: 2.412 – 2.484 GHz
• Operating Modes: Permanent ON or OFF, Auto timed, Holiday
• Boost Times: 1 or 2 hour
• Output Light: Yes
• Operating Temperature: 0°C to +40°C
• IP Rating: FSTWiFi – Intended for indoor use only
FSTWiFiTGV – IP66 rated suitable
for restricted external applications
• Minimum Depth of Wall Box: 25mm
• Multiple Device Support: Yes
• CE Compliant
• Dimensions: H = 85mm, W = 85mm, D = 44mm
Note: Not suitable for use with Discharge Lighting.
ON/OFF
indicator
Override
button
and Wi-Fi
connect
Wi-Fi
connection
indicator
Double pole switch BS1362 (1" x 1/4") fuse
