TIS TIS-4PL-E66D - Back View Connections; Input;Output Ports and Speaker Connections; Control Ports and Voltage Selection

INSTALLATION MANUAL
MODEL : TIS-4PL-E66D
NETWORK 4 ZONE AMPLIFIER
6
www.tiscontrol.com
TIS CONTROL LIMITED
Wanchai, Hong Kong
TIS CONTROL PTY LIMITED
SA, AUSTRALIA
Copyright © 2023 TIS, All Rights Reserved
TIS Logo is registered trademark of TIS CONTROL.
All of the specification are subject to change without notice.
BACK VIEW
SIDE VIEW
1) Pre-Out
2) Line in (Line 1 in APP)
3) Digital Coaxial Out
4) Digital Optical In
5) USB port
Screw holes for mounting brackets
6) Speaker out
7) Stereo/Bridge mode switch
8) Master Line In
9) Master Coaxial In
10) Master Optical In
11) Reset Button
12) RS232 Pass Through Port
13) RS232 Port
14) Network Output
15) Network Input
16) Voltage Selection
17) Switch (115V/230V)
18) Power Plug
