Application Note
September 2018
g. From the top menu choose “Tools” then “Program Table” or under Step 5, click on “Program”
to program the TD100 with the newly created TD100 strap table.
h. After successfully programming the strap table, power down the TD100 and Finch II and
proceed to section 5.4.
5.4 Performing Offset Calibration on the TD100
1. At this point it is assumed the TD80 transmitter has been removed and replaced with a TD100
transmitter.
2. Apply power to the Finch II / TD100 system. DO NOT INITIATE OFFSET CALIBRATION YET.
3. At the Finch II, select the compartment to be calibrated by pressing the “COMP SELECT” button. Verify
that the Finch II displays a volume (should not show any errors); procced to either step 4-5 or step 6.
4. Press and hold the following four buttons at the same time:
a. COMP SELECT
b. HORN BYPASS
c. ACK
d. DIM SLEEP
5. Continue to hold down the four buttons until the display flashes “CAL”, then release the buttons.
6. Alternately, the Finch II can enter Calibration mode by holding either ▲ or ▼ arrow while powering the
display.
7. The Finch II will then show the current volume of liquid in the tank.
8. Change the Offset Calibration to match the volume based on the previously recorded volume from the
TD80 transmitter by either pressing the ▲ or ▼ arrow on the Finch II.
9. Power cycle the Finch II / TD100 system.
10. The TD100 should now contain the same strapping table as stored in the TD80 and an Offset
Calibration has been applied.
5.5 Confirming Offset Calibration on the TD100
1. Power cycle the Finch II/TD100 system, wait until a level is displayed.
2. Confirm that the offset calibration has been applied. The level displayed should match the previously
recorded volume from the TD80 transmitter.
3. Power cycle the Finch II/TD100 system one more time. Observe the level displayed on the Finch II. It
should be consistent and should match the previously recorded volume from the TD80 transmitter.
4. Repeat Offset Calibration if the display is inconsistent each time a power cycle occurs or is not accurate.
