Hardware Version : 5.02 Document Version : 1.0.
TECHMAN ROBOT INC. 5F., No. 58-2, Huaya 2nd Rd., Guishan Dist., Taoyuan City, 333411 , Taiwan
46
Refer to the diagram below to remove the four securing screws and one grounding wire screw.
Refer to the diagram below to disconnect the wiring and take out the 24V PSU with the bracket.
Refer to the diagram below to remove the six bracket securing screws and take out the 24V PSU.
During installation, follow the reverse steps of the above procedure. If cable ties were cut, secure the
wires again in the original manner
