6
1. First, you must rst pair at least 1 remote control
2. To initiate system learning:
a. For single gate openers, hold the Button 2 and Button 3 on the remote control
simultaneously for at least 3 seconds, until LED 1 is turned on. When learning is
successfully completed, LED 1 will alternate between 3 seconds on and 1 second off.
b. For dual gate openers, hold the Button 2 and Button 4 on the remote control
simultaneously for at least 3 seconds, until LED 1 is turned on. When learning is
successfully completed, LED 1 will stay on.
3. The system will operate by itself and attempt to learn on its own. During this time do
not press any of the buttons on the remote control or set off the D-KEY or S-KEY of the
control board.
4. If system learning has been interrupted, then LED 1 will continue to ash.
After the remote has been successfully connected and the system has completed learning, the
remote has several functions.
1. Button 1 controls the gate opening and closing. Press once to open or to close.
2. Button 2 pedestrian mode. This mode partially opens the gate to allow pedestrians to pass
but not vehicles. Press Button 2 again to close the gate in pedestrian mode.
3. In Learning Mode, press Button 2 and Button 3 together for system learning of a single gate.
4. In Learning Mode, press Button 2 and Button 4 together for system learning of a dual gate.
5. Hold Button 3 and Button 4 together for 10 seconds to reset the system, when this is
completed, LED 1 will blink to indicate that system learning has been reset.
6. After having a remote pair, additional remotes can be paired without opening the control
box by holding Button 1 and Button 2 together. Hold Button 1 and Button 2 together for
ve seconds until a click can be heard from the control box, then press any button on the
remote that you wish to pair.
Condominium Mode supports many remotes without the risk of clashes. (You can still use up to
50 remotes even with Condominium Mode turned on.) Condominium Mode ensures that your
command will not be interrupted by another controller. In Condominium Mode, your command
will nish running before the system will take an input from another controller. If Condominium
Mode is turned off, the system will be able to take multiple commands simultaneously, which
may lead to instances of two controller trying to open the gate at the same time but leading to
the gate not actually opening.
1. To select Condominium Mode, hold Button 3 on a paired remote. After holding Button 3 for
10 seconds, the siren should beep twice.
2. To return to normal mode, hold Button 3 on a paired remote until the siren beeps once.
Our control board uses a 433 MHz RF receiver. It offers limited compatibility with other
remotes that use 433 MHz bandwidth.
3. Connecting with Other Controllers
4. System Learning Using the Controller
5. Using the Remote
6. Condominium Mode
