Toa EV-200M - [System Management Amplifier VM-2120;-2240]

58
*
1
0 dB = 1 V
*
2
Can be transformer-balanced with the addition of an optional IT-450 input transformer.
*
3
For connection of the Paging Microphone PM-660D with a remote control switch
*
4
An optional EV-200M Voice Announcement Board is required.
The messages and chime sound source must be pre-recorded into a CF (CompactFlash) card to be
inserted into the EV-200M Board.
*
5
An optional SV-200MA Surveillance Board is required.
*
6
Usable cable gauge: AWG26 – AWG20
*
7
Usable cable gauge: AWG24 – AWG12
Specifications of the AWG cables
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
Name label ............................................... 1
VR cover .................................................. 4
[VM-2120 (120 V AC version)]
Miniature type fuse 6.3 A ......................... 1
[VM-2120 (230 V AC version)]
Miniature type time-lag fuse T2.5 A ......... 1
[VM-2240 (120 V AC version)]
Miniature type fuse 8 A ............................ 1
[VM-2240 (230 V AC version)]
Miniature type time-lag fuse T3.15 A ....... 1
• Optional products
For both VM-2120 and VM-2240
Rack mounting bracket MB-36
Input transformer IT-450
Voice Announcement Board EV-200M
Surveillance Board SV-200MA
VM-2120 VM-2240
Two units stacking (VM-2120 or VM-2240)
Emergency broadcast (sequential control)
Broadcast priority control
Surveillance (failure detection) function
Power supply to Remote Microphone
0 – 40 °C
Panel: ABS resin
Case: Steel plate, paint
419 (w) x 143.3 (h) x 355.7 (d) mm
12.5 kg 14.5 kg
Model No.
Function
Operating Temperature
Finish
Dimensions
Weight
AWG
12
14
20
22
24
26
Diameter (Solid)
2.052 mm
1.628 mm
0.8128 mm
0.6426 mm
0.5105 mm
0.4039 mm
Cross-section (Stranded)
3.309 mm
2
2.082 mm
2
0.5189 mm
2
0.3243 mm
2
0.2047 mm
2
0.1281 mm
2
