8.5. Setting Functions (5. OPERATION SETTING)
8.5.1. Remote control (5-1 CONTROL FUNCTION SETTING) [Recording/erasure, playback and stop]
Using the control input terminals located on the rear panel, sentence recording and erasure, as well as
program playback can be remotely controlled by external equipment. It is possible to remotely play back and
stop the program set for Output 1 separately from the program set for Output 2.
Refer to p.68 for the operation procedures.
[Direct mode and binary mode]
Short the activation control input terminals when selecting the sentence number in remote recording and
remote erasure, and when selecting the program number in remote playback. Two different modes, direct
mode and binary mode, are made available as the method (control function) to select the sentence and
program numbers by means of the activation control terminals.
Note: The unit is factory-preset for direct mode.
[Activation control inputs 1-8 in direct mode]
Activation control terminal
Recording
Playback
/Erasure
Sentence No. Program No.
1 A001 P001
2 A002 P002
3 A003 P003
4 A004 P004
5 A005 P005
6 A006 P006
7 A007 P007
8 A008 P008
