Toa IP-A1SC15 - Dimensional Drawings

17
13. DIMENSIONAL DRAWINGS
4.5 (0.18")
222 (8.74")
4.5
(0.18")
211 (8.31")*
130 (5.12")
162 (6.38")
276 (10.87")
106
(4.17")
Mounting bracket
* Figure is a reference value.
141 (5.55")
25
(0.98")
3 - ø9
(3 - ø0.35")
36 (1.42")
50
(1.97")
Mounting holes
[Mounting bracket bottom surface]
[Rear]
[Front] [Side]
Unit: mm (in)
