18/35
8.2. Setting procedure by key operation
Set the counter to “000” using upper or down arrow keys. The following
displays are shown depend on the angle feature is on or off.
[Without angle setting]
[With angle setting]
Press and hold the “MD” key more than 2 seconds to move setting mode
i. Angle feature setting (Default: OFF)
Turn on or off the angle feature setting
[When turn on the angle feature]
・ At reset, power on or leaving setting mode after change the angle feature setting
from OFF to ON, an angle speed check will be automatically conducted.
・ At RUN mode, left display shows angle.
・ Enable to set the trigger torque
[When turn off the angle feature setting]
・ Trigger torque setting will be skipped
Select angle feature is ON or OFF using upper or down arrow keys. Press “MEM” key to
save setting and go to next. Press “MD” key to skip setting and go to next. Press “C” key to
go back to RUN mode (measurement mode).
